200w flexible monocrystalline solar panel

200W monocrystalline flexible solar panel for direct mounting to the roof of the vehicle with specific adhesive, includes MC4 connectors for connection.

CHARACTERISTICS:

• Maximum Power (Pmax): 200 W

• Optimum Operating Voltage (Vmp): 20.20 V

• Optimal Operating Current (Imp): 9.41 A

• Open Circuit Voltage (Voc): 24.00 V

• Short Circuit Current (Isc): 10.76 A

• Module Efficiency: 24.20%

• Operating Temperature: -20°C to +65°C

• Maximum System Voltage: 1000 V DC (IEC) / 600 V DC (UL)

• Maximum Series Fuse: 20 A

• Power Tolerance: 0 ~ +3%

• Solar Cell Type: MONOCRYSTALINE PERC

• Number of Cells: 4 × 9

• Dimensions: 1345 × 765 × 3mm

• Weight: 3.5kg

• Front Material: ETFE

• Junction Box: IP68

• Output Cables: TUV (2Pfg1169:2007), UL 4703, UL 44

• Connectors: SOLAR MC4 with twist lock system

• Cable Section: 4.0 mm²

• Nominal Operating Temperature (NOCT): 25 ± 2 °C

• Power Temperature Coefficient (Pmax): -0.44 %/°C

• Voltage Temperature Coefficient (Voc): -0.33 %/°C

• Current Temperature Coefficient (Isc): +0.055 %/°C

PERC TECHNOLOGY & MBB:

This panel incorporates PERC bifacial cell technology, which thanks to its rear passivation layer, reflects unused sunlight back to the cell, improving energy capture and reducing losses due to electron recombination. The result? More electricity generated with the same sunlight. Multiple bus bars allow better electron conduction, minimizing resistance losses and improving module durability. This means a more resistant, efficient panel with a longer useful life.
